Product Description

Galvanized steel wire ropes, very flexible, made of 6 strands, with a central fiber core. The strands are produced by stranding a group of roping wires around a fiber core. The fiber may be: Textile, Vegetal or Polypropylene.

For this kind of rope there is no guarantee for the uniformity of the tensile strength between the component wires. Thus, there is no guarantee for the minimum tensile strength of rope.

Considering this, there is prohibited to use this rope for industrial purposes such as lifting or traction.

Because of the high flexibility and the percentage of textile fiber contained in the rope, this has a high elongation grade.

For specific orders we can deliver also other lengths than usual ones.

公称直径 Nominal diameter mm	参考重量 Approximate weight kg/100 m		公称抗拉强度 Nominal tensile strength , MPa
			1770		1960		2160
			最小破断拉力Min. breaking load, kN
	纤维芯 FC	钢芯 IWRC	纤维芯 FC	钢芯 IWRC	纤维芯 FC	钢芯 IWRC	纤维芯 FC	钢芯 IWRC
12	59.8	66.5	95.1	102	105	113	116	125
14	81	91	129	139	143	154	158	170
16	106	118	169	181	187	201	206	222
18	135	150	214	230	236	254	261	281
20	166	185	264	283	292	314	322	347
22	201	224	320	343	353	380	390	420
24	239	266	380	408	420	452	464	500
26	281	312	446	479	493	530	545	587
28	326	362	518	555	572	615	632	681
30	374	416	594	638	656	706	725	781
32	425	473	676	725	747	804	825	889
34	480	534	763	819	843	907	931	1003
36	538	599	856	918	945	1017	1044	1125
38	600	667	954	1023	1053	1133	1163	1253
40	664	739	1057	1133	1167	1256	1289	1389
